PEEKRodBlack

PEEK - 0.875" dia x 72 Black Rod - 72 in Rod

72 in Rod

PEEK - 0.875" dia x 72 Black RodPEEK - 0.875" dia x 72 Black Rod - view 2PEEK - 0.875" dia x 72 Black Rod - view 3PEEK - 0.875" dia x 72 Black Rod - view 4PEEK - 0.875" dia x 72 Black Rod - view 5
Same-day shipping available
Quality certified
Expert support

This PEEK rod measures 0.875″ diameter × 72″ length, finished in black. In stock — price $184.93 per Each.

SpecificationValueTolerance
Shape / FormRod
Diameter0.875″Standard
Length72″Standard
ColorBlack
About This Product

PEEK (Polyether Ether Ketone) Black rod in 0.875" diameter x 72" long delivers outstanding mechanical strength along with exceptional heat and chemical resistance for demanding industrial applications. This high-performance PEEK rod is an excellent choice for machined parts that require durability, dimensional stability, and reliable performance in harsh environments.

Specifications

Shape

Rod

Length

72 in

Outer Diameter

0.875 in

Color

Black

Unit of Measure

Each

Other PEEK sizes

← All PEEKstock & specs

Price

$184.93 / Each

In Stock
21010 available
Available at 11 locations

Minimum order: 5 units

View PEEK Details
Ships same day if ordered by 2pm
Quality guaranteed
Quick Info
CategoryPEEK
FormRod
Length72 in
Outer Diameter0.875 in

Typical Properties — PEEK - 0.875" dia x 72 Black Rod

Peek
General
PropertyTest MethodUnitValue
DensityD792lb/in³ / g/cm³0.047 / 1.3
Water absorption (24 / 96 h immersion @ 73°F)ASTM D570mg / %5/10 / 0.06/0.12
Water absorption (Saturation in air @ 73°F, 50% RH)ASTM D570%0.20
Water absorption (Saturation in water @ 73°F)ASTM D570%0.45
Flammability rating (UL 94, 3 / 6 mm thickness)UL 94V-0/V-0
Mechanical
PropertyTest MethodUnitValue
Tensile strength (At yield / break)ASTM D638psi / MPa14,500 / 99
Tensile strain at breakASTM D638%15
Tensile modulusASTM D638psi / MPa566,000 / 3,900
Compressive stress (At 10% nominal strain)ASTM D695psi / MPa20,000 / 135
Izod impact (notched)ASTM D256ft·lb/in / J/m0.8 / 42
Rockwell hardnessASTM D785R120
Operating Environment
PropertyTest MethodUnitValue
Melting temperatureASTM D2133°F / °C640 / 335
Thermal conductivity (@ 73°F)ASTM C177Btu·in/ft²·h·°F / W/m·K1.7 / 0.24
Coefficient of thermal expansion (Avg. 73 – 140°F)ASTM D696μin/in/°F / μm/m/°C28 / 50
Coefficient of thermal expansion (Avg. 73 – 212°F)ASTM D696μin/in/°F / μm/m/°C28 / 50
Heat deflection temperature (264 psi (Method A))ASTM D648°F / °C320 / 160
Max service temperature (Short-term)°F / °C590 / 310
Max service temperature (Continuous (5,000 / 20,000 h))°F / °C480 / 245
Electrical
PropertyTest MethodUnitValue
Dielectric strengthASTM D149V/mil / kV/mm610 / 24
Volume resistivityASTM D257Ω·cm>10¹⁴
Surface resistivityASTM D257Ω>10¹³

Typical properties are provided for reference only. Values may vary based on processing conditions, form factor, and lot. Contact Ready Plastics for certified test data.
