FR4RodBlack
FR4 - 0.125" dia x 48" Black Rod
48 in Rod
Same-day shipping available
Quality certified
Expert support
Specifications
Shape
Rod
Length
48 inOuter Diameter
0.125 inStarting at
$9.79
per Each
In Stock
21010 availableAvailable at 11 locations
Ships same day if ordered by 2pm
Quality guaranteed
Quick Info
Typical Properties — FR4 - 0.125" dia x 48" Black Rod
Glass Epoxy Fr4Mechanical
PropertyTest MethodUnitValue
Tensile strengthpsi / MPa65,000 / 445
Compressive strengthpsi / MPa38,000 / 260
Flexural strength (LW -A 0.125″)psi / MPa60,000 / 410
Bond strengthpsi / MPa2,300 / 15
Shear strengthpsi / MPa21,500 / 145
Hardness (M scale)115
Izod impact strength at 49°C (LW)14.00
General
DescriptionValue
Specific gravity1.85
Flammability rating94V-0
Water absorption (24 hours)0.10
Operating Environment
PropertyTest MethodUnitValue
Maximum temperature°C / °F140 / 280
Typical properties are provided for reference only. Values may vary based on processing conditions, form factor, and lot. Contact Ready Plastics for certified test data.
