LERodBlack
LE - 0.14" dia x 48" Black Rod
48 in Rod
Same-day shipping available
Quality certified
Expert support
Specifications
Shape
Rod
Length
48 inOuter Diameter
0.14 inStarting at
$10.34
per Each
In Stock
21010 availableAvailable at 11 locations
Ships same day if ordered by 2pm
Quality guaranteed
Quick Info
Typical Properties — LE - 0.14" dia x 48" Black Rod
Phenolic Grade LeGeneral
DescriptionValue
Flammability rating94HB
Water absorption (24 hours)1.8
Specific gravity1.34
Operating Environment
PropertyTest MethodUnitValue
Maximum operating temperature°C / °F125 / 255
Mechanical
PropertyTest MethodUnitValue
M-scale hardness100
Shear strengthpsi / MPa13,500 / 93
Tensile strengthpsi / MPa36,000 / 245
Compressive strengthpsi / MPa13,000 / 89
Flexural strength (LW -A 0.125″)psi / MPa18,000 / 120
Bond strengthpsi / MPa1,900 / 13
Izod impact strength at 49°C (LW)1.35
Typical properties are provided for reference only. Values may vary based on processing conditions, form factor, and lot. Contact Ready Plastics for certified test data.
