LERodBlack
LE - 0.14" dia x 48" Black Rod - 48 in Rod
48 in Rod
Same-day shipping available
Quality certified
Expert support
This LE rod measures 0.14″ diameter × 48″ length, finished in black. In stock — price $10.34 per Each.
| Specification | Value | Tolerance |
|---|---|---|
| Shape / Form | Rod | |
| Diameter | 0.14″ | Standard |
| Length | 48″ | Standard |
| Color | Black | |
Specifications
Shape
Rod
Length
48 inOuter Diameter
0.14 inColor
Black
Unit of Measure
Each
Other LE sizes
- LE - 0.75" dia x 48" Black Rod — $24.82
- LE - 0.787" dia x 48" Black Rod — $36.11
- LE - 3" dia x 48" Black Rod — $568.34
- LE - 0.062" dia x 48" Natural Rod — $6.19
- LE - 6.000" 48 x 48 Natural Sheet — $6144.06
- LE - 4.000" 48 x 48 Natural Sheet — $4096.03
- LE - 0.015" 48 x 96 Natural Sheet — $38.01
- LE - 0.156" 36 x 48 Natural Sheet — $124.34
- LE - 0.187" 36 x 48 Natural Sheet — $149.06
- LE - 0.375" 48 x 96 Natural Sheet — $767.99
- LE - 0.687" 48 x 96 Natural Sheet — $1406.99
- LE - 1.000" 36 x 48 Natural Sheet — $767.99
Price
$10.34 / Each
In Stock
21010 availableAvailable at 11 locations
Ships same day if ordered by 2pm
Quality guaranteed
Quick Info
CategoryLE
FormRod
Length48 in
Outer Diameter0.14 in
Typical Properties — LE - 0.14" dia x 48" Black Rod
Phenolic Grade LeGeneral
DescriptionValue
Flammability rating94HB
Water absorption (24 hours)1.8
Specific gravity1.34
Operating Environment
PropertyTest MethodUnitValue
Maximum operating temperature°C / °F125 / 255
Mechanical
PropertyTest MethodUnitValue
M-scale hardness100
Shear strengthpsi / MPa13,500 / 93
Tensile strengthpsi / MPa36,000 / 245
Compressive strengthpsi / MPa13,000 / 89
Flexural strength (LW -A 0.125″)psi / MPa18,000 / 120
Bond strengthpsi / MPa1,900 / 13
Izod impact strength at 49°C (LW)1.35
Typical properties are provided for reference only. Values may vary based on processing conditions, form factor, and lot. Contact Ready Plastics for certified test data.
